- ✅【Application】 For 55-87 GM. (Muscle Car, Classic Car, Trucks.etc) Fit GM rear wheel drive applications that were originally equipped with a Small Block or Big Block Chevy engine and traditional rear sump oil pan. Part Number: 302-1
- ✅【Performance】 Cast aluminum appearance with clean exterior styling. Provide maximum clearance to the chassis. Engine location may need to be adjusted (up/ down or fore/ aft). Cast Aluminum Benefits: 1)Lightweight: Boosts fuel efficiency, max chassis clearance. 2)High-strength: Ensures structural safety. 3)Durable: Resists oil, temp changes. 4)Anti-corrosion: Forms oxide film to prevent corrosion. 5)Rapid heat dissipation: Stabilizes oil, extends engine life.
- ✅【Features】 This LS Swap Retrofit Aluminum Oil Pan is designed for use a full length windage tray. Maximum crankshaft stroke: 4.25”. Sump Oil Capacity: 5.5 Quarts. Total Oil Capacity with stock oil filter: 6 Quarts.
- ✅【Package Includes】 1x Oil Pan; 1x Oil Pan Gasket; 1x Sump Baffle; 1x Pick-up Tube; 1x Sump Plug; 1x Oil Filter Stud; 1x Oil Passage Cover; 1x Oil Passage Gasket; 1x O-ring; 23x Bolts.
- ✅【Problem Solving】 Our swap retrofit aluminum oil pan kit offers a lower profile for added ground clearance. It can help you easily solve a lot of problems, including oil leakage, blocked oil path by impurities, engine overheating, car valve noise, engine failure due to lack of lubrication, and oil pressure warning.
Replace Part Number: 302-1
Application:
Please Check the Application Before Ordering！
- For 1955-1987 GM Muscle Car;
- For 1955-1987 GM Classic Car;
- For 1955-1987 GM Trucks;
- For LS Gen lll and GEN IV V8 LS1 LS2 LS3 LS6LSX 4.8L 5.3L 5.7L 6.0L 6.2L Engines.
Specifications:
- Condition: Brand New;
- Material: Aluminum ;
- Surface Finish: Corrosion Resistance;
- Sump Location: rear;
- Oil Pan capacity: 5.5 quarts;
- Total Oil capacity: 6.0 quarts with stock filter.
Package Includeds:
- 1x Oil Pan;
- 1x Oil Pan Gasket;
- 1x Sump Baffle;
- 1x Pick-up Tube;
- 1x Sump Plug;
- 1x Oil Filter Stud;
- 1x Oil Passage Cover;
- 1x Oil Passage Gasket;
- 1x O-ring;
- 23x Bolts. (100% Brand New Never Used Or Installed)
Attention：
Various vehicles may require different oil filter bolt sizes. We provide a standard model. If incompatible, please use your vehicle's original oil filter stud or purchase a suitable one.
